ASTM D523 Standard Gloss Tester Portable With 10 x 20mm Measurement Spot

China ASTM D523 Standard Gloss Tester Portable With 10 x 20mm Measurement Spot supplier
ASTM D523 Standard Gloss Tester Portable With 10 x 20mm Measurement Spot supplier ASTM D523 Standard Gloss Tester Portable With 10 x 20mm Measurement Spot supplier ASTM D523 Standard Gloss Tester Portable With 10 x 20mm Measurement Spot supplier

Large Image :  ASTM D523 Standard Gloss Tester Portable With 10 x 20mm Measurement Spot

Product Details:

Place of Origin: Beijing
Brand Name: SADT
Certification: CE ISO9001
Model Number: GT60N

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Packaging Details: Standard package
Delivery Time: Within 3 days after receiving payment
Payment Terms: T/T in advance
Supply Ability: 50pcs/week
Contact Now
Detailed Product Description
Application: Paint, Coating, Printing, Ceramics , Metal, Plating Layer Measuring Range(Gu): 0~1999
Memory: 10 Group Of Data Communication Interface: USB
Dimension (mm): 83×46×30 Net Weight(g): 100

ASTM D523 Standard Gloss Tester Portable With 10 x 20mm Measurement Spot





The serial of GT60 glossmeters are designed and manufactured according to international standard ISO2813, ASTMD523, DIN67530 and China standard GB9754, GB9966, GB/T3891. The technical parameters up to JJG696-2002.

Applications:


1. Measurement of Paint and Dope surface gloss on Car, Electronic appliance and Musical
instrument industry.
2. Measurement of floor board, marble, granite and ceramic tile gloss on architecture, decoration industry.
3. Measurement of printing ink and paper on Printing and Casing industry.
4. Measurement of the others need to be measured.
5. Hard drawn aluminum alloys





Standards:


ISO2813 Paints and varnishes -- Determination of secular gloss of non-metallic paint films at 20 degrees, 60 degrees and 85 degrees.
ASTM D 523 Standard Test Method for Secular Gloss.
DIN 67530 The reflect meter as an aid in evaluating gloss on level paint and plastic surfaces.
ISO7668 Anodized aluminum and aluminum alloys-Measurement of secular reflectance and secular gloss at angles of 20°,60°and 85°.



Specifications:



Model GT60N
Application Paint, coating,printing,ceramics , metal,plating layer
Measuring
Range(Gu)
0~1999
Readout
Error(Gu)
±0.5 (0~99.9)
±0.5%(100~1999)
Repeatability ±0.2 (0~99.9)
±0.2%(100~1999)
Aperture (mm) 60°
Measurement
Spot (mm)
10×20
Window Size
(mm)
14×28
Memory 10 group of data
Communication
Interface
USB
Software My Gloss
Power Supply 1.5V AAA
Dimension
(mm)
83×46×30
Net Weight(g) 100
Standards ISO2813, ASTM D523, DIN-67530, ISO7668, GB/T9754, GB/T7706, GB/T9966.6



ASTM D523 Standard Gloss Tester Portable With 10 x 20mm Measurement Spot





Company Information



Sino Age Development Technology, Ltd. (SADT), established in 1993, is a leading manufacturer / supplier of measuring andtesting instrument, specialized in NDT and quality control fields.

We have our own HARTIP series portable hardness testerssince 1995.



Now our main products cover portable and bench type hardness tester, ultrasonic thickness gauge, digital concrete hammer, gloss meter, colorimeter, roughness tester, handheld metallurgical microscope, ultrasonic flaw detector and so on.



Our main overseas markets are: USA, Canada, Germany, France, Netherlands, Finland, Italy, Czech Republic, Poland, Lithuania, Estonia, Serbia, Greece, Turkey, Australia, New Zealand, Korea, Taiwan, Singapore, Thailand, Indonesia, Malaysia, Vietnam, India, Pakistan, Iran, UAE, Egypt, South Africa, Mexico and Columbia, Peru and etc.



We are professional producer with ISO 9001 quality system. Most of the products are applied with CE certificate.
