520g Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth

China 520g  Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth supplier
520g  Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth supplier 520g  Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth supplier 520g  Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth supplier 520g  Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth supplier 520g  Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth supplier 520g  Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth supplier 520g  Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth supplier

Large Image :  520g Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth

Product Details:

Place of Origin: Beijing
Brand Name: SADT
Certification: CE ISO9001
Model Number: GMS

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Price: USD600-1000/Pcs
Packaging Details: Standard package
Delivery Time: Within 3 days after receiving payment
Payment Terms: T/T in advance
Supply Ability: 50pcs/week
Contact Now
Detailed Product Description
Aperture: 20°, 60°, 85° Memory: 900 Data Or 30 Groups, CF Card (optional)
Dimension (mm): 164×58×88 Net Weight(g): 520
Readout Error(Gu): ±1.5 (0~120) ±1.5%(120~2000) Repeatability: ±0.5 (0~120) ±0.5%(120~2000)
Warranty: 1 Year

Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth





GM Series gloss meters are designed and manufactured according to internation standards ISO2813, ISO7668, ASTM D523, ASTM D2457 and China standards GB/T9754, GB/T13891, GB/T7706 and GB/ T8807. The technical parameters is up to JJG696-2002. GM Series gloss meters can be widely used to measure painting, coating, plastic, ceramics, leather products, paper, printing, floor materials and so on.





KEY FEATURES

  • Precision appearance design, more suitable for human characteristic, easy to use.
  • Three-angle gloss data is displayed simultaneously, can satisfy various require-ments. (Only for GMS)
  • Large memory for measurement data.
  • Latest Bluetooth function and removable memory card to transmit data conveniently.
  • Speical designed gloss software to analysis data and output.
  • Prompt for low battery and full memory.

With internal Bluetooth module or USB interface, GM gloss meter can transfer data with PC easily. The measuring data also can be exported to printer via printing interface. Optional SD card makes the memory as large as you want .



Specifications:



 Model  GMS
 Application  Painting, printing, floor material, plastic, ceramics, leather, hardware, plating
 Measuring Range(Gu)  0~120, 120~2000@ 20°
 0~120, 120~1000 @ 60°
 0~120, 120~160 @ 85°
 Readout Error(Gu)  ±1.5 (0~120)
 ±1.5%(120~2000)
 Repeatability  ±0.5 (0~120)
 ±0.5%(120~2000)
 Aperture (mm)  20°, 60°, 85°
 Measurement Spot (mm)  10×10 @ 20°
 9×15 @ 60°
 5×38 @ 85°
 Memory  900 data or 30 groups, CF card (optional)
 Interface  USB / printer /Bluetooth (Bluetooth is only avalaible for GMS)
 Software  Data managing software
 Power Supply  +5V, AA*4
 Working Environment  10~40°C, <85%RH,
 Dimension (mm)  164×58×88
 Net Weight(g)  520
 Standards  ISO2813, ISO7668, ASTMD 523, ASTM D2457, GB/T9754, GB/T13891, GB/T7706, GB/T8807







_01_02

520g  Large memory Precision USB Interface Gloss Meter Three-angle With Internal Bluetooth

_04_05_06_07_08
