HARTIP2500 Metal Hardness Tester / Leeb Hardness Tester RP Reading Probe

China HARTIP2500 Metal Hardness Tester / Leeb Hardness Tester RP Reading Probe supplier
HARTIP2500 Metal Hardness Tester / Leeb Hardness Tester RP Reading Probe supplier HARTIP2500 Metal Hardness Tester / Leeb Hardness Tester RP Reading Probe supplier HARTIP2500 Metal Hardness Tester / Leeb Hardness Tester RP Reading Probe supplier

Large Image :  HARTIP2500 Metal Hardness Tester / Leeb Hardness Tester RP Reading Probe

Product Details:

Place of Origin: China
Brand Name: SADT
Certification: SGS CE ISO9001
Model Number: HARTIP2500

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Packaging Details: Carring case with carton
Delivery Time: 3-7 working days
Payment Terms: T/T, Western Union, Paypal
Contact Now
Detailed Product Description
Principle: Leeb Hardness Measurement Accuracy / Repeatability: ±0.3% @ HL=800 / ±2HL
Display: High Contrast Color TFT 240 X 320 Hardness Scale: HL/HRC/HRB/HB/HV/HS/HRA/σb
Memory: 999 Data Power Supply: AA Alkaline Battery / USB Power Supply
Dimension (mm): 145x70x30 Warranty: 1 Year

Portable Hardness Tester HARTIP2500 + RP Reading Probe

RP reading probe is an impact device for Leeb hardness tester, which not only can work with SADT series hardness tester as external probe with cable, but also can work independently as a single tester. There is a Li-ion battery inside the probe, which can be charged via USB supplier. All parameters of the tester can be set from main tester. The main setup of material and scale from factory default is steel and HRC, which can meet much of routine job for hardness testing. HARTIP 2500 + reading probe become a cost effective option - One payment for Two.

Advantages

›› Patent dual- coil technology
›› Equipped with digital probes only
›› Cost- effec tive with reading probe (optional)
›› High repeatability accuracy: +/-2 HL (or 0.3% @HL800)
›› High linear accuracy for any angles
›› TFT color display
›› Auto compensate error for different impac t direc tion
›› Powered by AA batter y or USB power supply
›› The tester can be attrac ted to the workpiece with magnetic base (optional)
›› Statistics value can be calculated automatically
›› Up to 10 kinds of menu language
›› Data managing sof tware on PC
›› Power on/off automatically or manually


Specification


PrincipleLeeb hardness measurement
Accuracy / Repeatability±0.3% @ HL=800 / ±2HL
Display High contrast colorTFT 240 x 320
Hardness scaleHL/HRC/HRB/HB/HV/HS/HRA/σb
Measuring rangeHL100-960 / HRC0.9-79.2 / HRB1.2-140 / HB1-1878 / HV1-1698 / HS0.5-128 / HRA7-88.5 / σb(rm)24-6599N/mm2
Probe

Digital probe D/ C/DC/D+15/DL/E
Wireless probe D C/DC/D+15/DL/E (optional), Reading probe D (optional)

Materials and conversioncurves 11 common metal materials, 75 curves
Memory 999 data999 data
Statistics functionAverage / Max. / Min. / S. value
Re-calibrationAllowed by user
IndicatorLow battery
Language,En g l i s h , S i m p l i f i e d Chinese, Trad i tiona l Chinese, Russian , Korean, Fre nch , Italian , German, Turkish, Spanish
Interface USB / Bluetooth (optional)USB / Bluetooth (optional)
Power on/offAuto / Manual
Power supplyAA alkaline battery / USB power supply
Working environment-20°C~+70°C
Dimension (mm) 1145x70x30
Net weight (g)145
StandardsConforming to ASTM A956, DIN 50156, GB/T 17394-1998


Standard package
HARTIP 2500
HARTIP 2500 main unit 1
Digital probe D 1
Test block D 1
Small support ring 1
Cleaning brush 1
Probe cable 1
USB cable 1
Operation manual 1
Test Certificate 1
Carrying case 1

Optional accessories
Digital probe C/DC/D+15/DL/E
Reading probe D
Wireless probe D C/DC/D+15/
DL/E
Special support rings
Standard support ring for
probe D
Small support ring
Impact body D
Carbide ball tip D
Test block D with certificate
Test block D w/o certificate
