Product Details:

Place of Origin: Beijing
Brand Name: SADT
Certification: CE /ISO9001
Model Number: Hartip1800 D&DL

Payment & Shipping Terms:

Minimum Order Quantity: 1pc
Packaging Details: Standard package
Delivery Time: With 3 days after receiving payment
Payment Terms: T/T, Western Union
Supply Ability: 50pcs/week
Contact Now
Detailed Product Description
BRAND: SADT Material: 11 Common Metals
Impact Direction: Auto Impact Direction Language: 10 Type Language

ASTM A956 Portable Hardness Tester , OLED Display Leeb Hardness Measurement HARTIP1800D/DL

HARTIP1800 is an advanced state-of-the-art palm sized metal hardness tester with many new features. Which is light weight, easy operation, integrated design, high contrast display, low operating temperature, auto compensating for impact direction and etc. HARTIP 1800 can be widely used for measuring hardness of almost all ferrous and non-ferrous metal materials for scale of Leeb hardness, Rockwell C & B, Brinell, Vickers, Shore and Strength.


HARTIP 1800 has a memory capacity of 400 blocks and 360, 000 data which can be download to computer via USB. The 3.7V Li-ion rechargeable battery inside HARTIP 1800 can be charged via USB from PC or via individual battery charger from mains wall power. With data software for PC, customers can download measuring values from HARTIP 1800 to PC and make process such as save, delete, create testing report and export them to Excel.

HARTIP1800 D&DL is equipped with two-in-one probe. With unique two-in-one probe, HARTIP1800 D&DL can convert between probe D and probe DL simply by changing impact body. It's more economic than buying them individually. It has the same configuration with HARTIP1800 except two-in-one probe.

Adantages:

Integrated design , easy operation ,
Universal impact direction, it does not need to setup different impact direction, it will be recognized automatically Digital with high contrast OLED display
Wide operating environment: -40oC-70oC
High accuracy: +/-2 HL (or 0.3% @HL800)
Dual values( Leeb value and one conversion value) can be displayed at the same screen
Four display modes: single value shown in big letter or multi-values shown in batch
Auto compensate error for different impact directionHuge memories, data can be recalled easily
Up to 10 kinds of menu language
It can connect to computer by USB or Bluetooth
USB and Bluetooth interface, it can connect micro-printer wirelessly
Customer re-calibration allowed , 3.7 V Li-ion rechargeable battery , it can be charged by USB or power source Statistics value can be calculated automatically
With strength conversion value
Power on/off automatically or manually
Packed in rigid carrying case







HARTIP 1800 D/DL Durometer

KEY FEATURES
High accuracy ±2HL 0.3%
Palm sized and easy operation
High contrast LED display
Wide operating temperature: -40° C~+60° C
Auto switch on & off
Micro-printer can be used on site
Recalibration allowed by user
Model

HARTIP 1800  D/DL Durometer

Principle

Leeb hardness measurement

Accuracy

+/-2HL(0.3%@HL=800)

Display

digital with high contrast LED

Display mode
Normal or flip
Hardness scale

HL/HRC/HRB/HB/HV/HS/σb

Measruing range

HL200-960 / HRC19-70 / HRB13-109 / HB20-655 / HV80-940 / HS32-99.5 / HRA30-88

Impact devic


D/DL 2-in-1 (Internal, optional)

Materials

11 common metal materials

Memory

360, 000 data in 400 blocks

Statistics function

Average / Max. / Min. / value

Recalibration

Allowed by user

Interface
USB for data transferring to PC and charging battery
Indicator

Low battery

Power on/off

Auto

Power supply
3.7v Li-ion rechargeable battery
Working environment

-40~+80°C

Standard
ASTM A956
Dimension (mm)

148x44x22

Net weight (g)

110
